A gravel ride can be whatever you want it to be: go for speed, go for distance, go for fun, go for an escape. No matter your goal, Warbird C GRX 810 2x is a comfortable and efficient way to get there. The carbon frame with Class 5™ Vibration Reduction System (VRS) tames harsh roads. Our gravel race geometry grants you control on ruinous roads. Thoughtful mounting points provide places for everything from extra bottles to a light bikepacking setup. Shimano’s GRX 810 2x drivetrain has proven itself as a dependable, high-performance gravel group with plenty of gear range for windy flats and steep climbs. Put it all together and you’ve got one of the best gravel bikes out there.
- Salsa GRX 810 Carbon complete bike
- Waxwing Carbon fork with anythin cage mounts
- Shimano GRX 810 2x groupset
- hydraulic Shimano GRX disc brakes
- WTB EZR i23 rims
- Teravail Cannonball 700 x 42 mm tyres
Features:
Class 5 VRS:
The Class 5™ Vibration Reduction System has specially shaped?seatstays?with a tall, thin, vertically oriented profile that promotes vertical compliance by allowing the?seatstays?to "flex" outwards on impacts. The horizontally oriented?chainstays?work to resist torque and maintain a laterally stiff rear end. The?seatstays?and?chainstays?lack bridges, furthering the full length of the stays to contribute to flexibility. And a rear thru-axle delivers precise tracking while allowing the?seatstays?to provide that incredible compliance
Interior Junction Control Molding Technology
We use internal molds at all the main front triangle junctions during layup and curing. This allows for precise control of wall thickness and inner wall smoothness in these areas. This process increases compaction and reduces voids and wrinkles in critical high stress zones. The end result is a top-quality carbon frame that delivers consistent high performance
Warbird Geometry
Warbird features the latest evolution of our already industry leading gravel racing geometry. Warbird places the rider in a position that can be maintained for hours on end over bumpy B-roads and loose surfaces, drastically reducing fatigue. A low bottom bracket and stable wheelbase help keep the tires planted and boost confidence. Long top tubes paired with short stems provide increased stability at high speed and on rough descents
Waxwing Fork
This fork features carbon construction with an aluminum steerer and utilizes a 12 x 100 mm thru axle for true tracking and flat mount brake for quick setup. Most importantly, the fork includes an incredible array of accessory features:
- Three-Pack mounts accept either water bottle cages or Anything Cages for increased hydration or gear carrying capacity
- Mid-blade mounts allow the attachment of our Down Under Low Rider Rack for front pannier use
- Internal Dynamo Hub Cable Routing means clean cable routing for those upgrading to dynamo front hubs
- Fender mounts mean more pleasant riding in rainy weather, allowing you to tack on more training miles
Dual Wheel Size
Compatible Warbird fits up to 700c x 45 mm OR 650b x 2.0" wheels/tires. We offer models with each spec so you can choose the wheel size that best meets your needs, or set up a second wheel set so your Warbird is optimized for the race course at hand
Integrated Toptube Bag Mount
Bolt on your Salsa EXP Series Top Tube Bag for secure connection and elimination of strap wear
Generous Water Bottle Capacity
Helps you stay hydrated during ultra-endurance training rides and races. 2–3 bottle mounts inside main triangle (56 cm and above receive 3), 1 accessory mount on underside of downtube, 2 bottle mounts possible on fork via Three-Pack mounts
Refined Drivetrain Compatibility
Designed to accept 1x, 2x, and current electronic offerings
Stealth Dropper Post Compatible
Accepts 27.2 mm dropper posts for more confident descending at high speeds on rough, unpredicatable gravel roads. Internal stealth routing when running 1x setups
Fender Mounts
Fenders allow for longer, more pleasant rides in wet weather Rear Rack Friendly Compatible with the Salsa Wanderlust Rack when using the optional Salsa Rack-Lock seat collar
Product safety information
Manufacturer information:
Cannondale
, ,
| Laufradgröße / Wheelsize |
700c |
| Rahmen / Frame |
Warbird Carbon |
| Gabel / Fork |
Waxwing |
| Lenker / Handlebar |
Zoom DR-AL-199BTFOV |
| Griffe / Grips |
Anti-Slip Silicone handlebar tape |
| Vorbau / Stem |
Salsa Guide |
| Steuersatz / Headset |
Cane Creek 40 |
| Bremshebel / Brake Lever |
Shimano GRX RX810 |
| Schalthebel / Shifters |
Shimano GRX RX810 |
| Bremsen / Brakes |
Shimano GRX RX810, Shimano SM-RT60 rotors (160 mm) |
| Kurbel / Crank |
Shimano GRX RX810-2, 48/31 |
| Innenlager / Bottom Bracket |
Shimano compatible |
| Pedale / Pedals |
- |
| Kette / Chain |
Shimano HG601 |
| Kassette / Cassette |
Shimano HG700 11-34, 11-x |
| Umwerfer / Front Derailleur |
Shimano GRX RX810 |
| Schaltwerk / Rear Derailleur |
Shimano GRX RX810 |
| Nabe, vorn / Hub front |
Thru-Axle, 12x100mm |
| Nabe, hinten / Hub Rear |
ShThru-Axle, 12x142mm |
| Spokes / Speichen |
Stainless steel, 14g |
| Felgen / Rims |
WTB EZR i23 TCS, 28h |
| Sattel / Saddle |
WTB SL8 Medium Steel SL |
| Sattelstütze / Seat Post |
Salsa Guide |
| Sattelklemme / Seat Clamp |
- |
| Reifen / Tyre |
Teravai Cannonball 700 x 42, durable casingl |
| Schutzbleche / Mudguards |
- |
| Gepäckträger / Racks |
- |
| Licht / Light |
- |
| Gewicht / Weight |
- |
Allgemeine Produkthinweise: Preis- und Farbänderungen vorbehalten. Hinweise zu abweichenden Bike-Spezifikationen: Aufgrund der aktuell durch das Corona-Virus verursachten Probleme in den Lieferketten sämtlicher Zulieferer kann das Bike, entgegen der hier kommunizierten Spezifikation, mit abweichenden Komponenten ausgeliefert werden.
PLEASE BE AWARE THERE CAN BE CHANGES DUE AVAILABILITY AND OTHER REASONS
|
49cm |
52,5cm |
54,5cm |
56cm |
|
|
61cm |
| Sitzrohrlänge (Mitte - Oberkante) / Seat Tube Length (C-T) |
390 |
440 |
457 |
510 |
520 |
545 |
570 |
| Oberrohrlänge / Top Tube Length (effective) |
499 |
525 |
545 |
560 |
575 |
590 |
610 |
| Steurohrwinkel / Head Angle (°) |
71° |
70,75° |
70,75° |
70,75° |
70,75° |
70,75° |
70,75° |
| Sitzrohrwinkel / Seat Angle (°) |
75° |
74° |
73° |
73° |
73° |
73° |
72,5° |
| Steurohrlänge / Headtube Length |
90 |
120 |
140 |
160 |
180 |
200 |
220 |
| BB Drop |
70 |
70 |
70 |
70 |
70 |
70 |
70 |
| Kettenstrebenlänge / Chain Stay Length |
430 |
430 |
430 |
430 |
430 |
430 |
430 |
| Fork Rake |
50 |
50 |
50 |
50 |
50 |
50 |
50 |
| Radstand / Wheelbase |
996,14 |
1011,96 |
1022,39 |
1038,21 |
1054,03 |
1069,85 |
1084,54 |
| Überstandshöhe / Standover |
670,20 |
714,48 |
744,30 |
770,11 |
785,96 |
808,40 |
830,55 |
| Reach |
360,24 |
368,13 |
371,97 |
381,19 |
390,42 |
399,65 |
407,74 |
| Stack |
517,85 |
547,09 |
565,97 |
584,85 |
603,73 |
622,61 |
641,50 |
| Vorbaulänge / Stem Length |
70 |
70 |
80 |
90 |
90 |
100 |
110 |
| Kurbellänge / Crank Arm Length |
165 |
170 |
170 |
172,5 |
172,5 |
1725 |
175 |
| Lenkerbreite / Handlebar Width (dropcenter - center) |
380 |
400 |
420 |
440 |
460 |
460 |
460 |
Alle Angaben in mm sofern nicht anders angegeben / All measurements in mm unless otherwise stated
Irrtümer vorbhalten / Errors excepted
